Guangzhou Kaihui Electronics Co., Ltd. is one of the leading manufacturers and suppliers of poe driver dc48v 120w in China. With abundant experience, our factory offer high quality products made in China with competitive price. Welcome to contact us for customized service.
Parameter | |||||
Item NO | K26S-U120S48 | ||||
Output | Output Voltage | +48V | |||
Rated Current | 2.5A | ||||
Current Range | 0-2.5A | ||||
Rated Power | 120W | ||||
Ripple | 480mVp-p | ||||
Adjustable Output Range | ±10% | ||||
Output Accuracy | ±1% | ||||
Line Regulation | ±0.5% | ||||
Load Regulation | ±0.5% | ||||
Set up,Rise,Keep up time | 500ms, 50ms, 20ms | ||||
Input | Input Voltage Range | 90~264V AC;110~360V DC | |||
Input Current | 2A/115V;1A/230V | ||||
Input Frequency | 47~63Hz | ||||
Efficiency | 88% | ||||
Inrush Current | 30A@230V | ||||
Leakage Current | <0.5mA@240V | ||||
Protection | Over Load Protection | 105~150%, TYPE:HICCUP RESET:AUTO RECOVER | |||
Short Circuit Protection | TYPE:HICCUP RESET:AUTO RECOVER | ||||
Over Voltage protection | 54-60V | ||||
Environment | Working Temp.,Humidity | -10~50℃,10~90% RH，No condensation | |||
Storage Temp.,Humidity | -20~85℃,10~95% RH | ||||
Temp.,Drift | ±0.03%/℃(0~50℃) | ||||
Vibration | 10~500Hz, 2G 10min /1cycle, PERIOD FOR 60min EACH AXES | ||||
Safety&EMC Standards | Safety Standards | GB4943,EN60950 | |||
Withstand Voltage | I/P-O/P,I/P-FG:1.5KV,O/P-FG:0.5KV DC 1min | ||||
Insulation Resistance | I/P-O/P, I/P-FG, O/P-FG:500VDC / 100M Ohms | ||||
EMC Standards | GB9254,EN55022 CLASS B | ||||
Others | Dimension | 115*59*28mm CASE：K826S | |||
Weight | 0.3kg | ||||
