Audio Smps 28V 200W

Model No.

K18N-UP200S28

Output

Output Voltage

+28V

Rated Current

7.2A

Current Range

0-7.2A

Rated Power

201.6W

Ripple & Noise

280mVp-p

Adjustable Output Range

27~30V

Output Accuracy

±1%

Line Regulation

±0.5%

Load Regulation

±0.5%

Input

Input Voltage Range

90-264V AC

Input Current

5A/115V, 2.5A/230V

Input Frequency

50/60Hz

88%

Inrush Current

30A@230V

Leakage Current

<0.35mA@240V

Protection

Over Load Protection

110~200% Type: Hiccup Reset: automatic recovery

Short Circuit Protection

Type: Hiccup Reset: automatic recovery

Over Temp, protection

Cover temp.>105℃, output closed, automatic recovery

Environment

Working Temp, Humidity

-10~50℃, 10~90% RH, No condensation

Storage Temp, Humidity

-20~85℃, 10~95% RH

Temp, Drift

±0.03%/℃ (0~50℃)

Safety&EMC Standards

Safety Standards

GB4943 EN62368

Withstand Voltage

I/P-O/P: 1.5KV; I/P-FG: 1.5KV; O/P-FG: 0.5KV DC 1min

EMC Standards

GB9254 EN55022 CLASS B

Others

Dimension

127*82*45mm

Weight

0.5kg
