| Parameter | |||||
| Item No | K18-UP400S42 | ||||
| Output | Output Voltage | +42V | |||
Rated Current | 9.5A | ||||
Current Range | 0-9.5A | ||||
Rated Power(with cooling fan) | 350W | ||||
| Rated power(without cooling fan) | 400W | ||||
Ripple | 420mVp-p | ||||
Output Accuracy | ±1% | ||||
Set up,Rise,Keep up time | 500ms, 50ms, 20ms/230VAC | ||||
| Input | Input Voltage Range | 88~264V AC,100~370VDC | |||
Input Current | 6A/115V,3A/230V | ||||
Input Frequency | 50/60Hz | ||||
Efficiency | 93% | ||||
Inrush Current | 15A@115VAC,30A@230VAC | ||||
Leakage Current | <3.5mA@240V | ||||
| Protection | Over Load Protection | 110~200%,Hiccup,automatic recovery | |||
Over temp. Protection | when TS1 position>105 degree,it will be protected,then automatic recovery. | ||||
Environment | Working Temp.,Humidity | -20~60℃,10~90% RH，No condensation | |||
Storage Temp.,Humidity | -20~85℃,10~95% RH | ||||
Safety&EMC Standards | Safety Standards | GB4943,EN60950 EN62368 | |||
Withstand Voltage | I/P-O/P:3kv,I/P-FG:1.5KV,O/P-FG:0.5KV DC 1min | ||||
EMC Standards | EN55015 CLASSB;EN61000-3-2 | ||||
| Others | Dimension | 127*82*39mm(L*W*H) | |||
Q1: Can you do OEM and ODM?
A1: Yes, OEM and ODM are both acceptable. The material, color, style can customize, the basic quantity we will advise after we discuss.
Q2: Do you have the test and audit service?
A2: Yes, we can assist to get the designated test report for product and the designated factory audit report.
Q3:How many for your engineers team to design the power supply?
A3:12 people
