SPECIFICATIONS | ||
Item NO | K06L-U100S24 | |
OUTPUT | OUTPUT VOLTAGE | +24VDC |
OUTPUT RATED CURRENT | 4.16A | |
CURRENT RANGE | 0-4.16A | |
RATED POWER | 100W | |
RIPPLE & NOISE | 240mVp-p | |
DC VOLTAGE ADJ. | ±5% | |
ACCURACY | ±1% | |
LINE REGULATION | ±0.5% | |
LOAD REGULATION | ±0.5% | |
SETUP, RISE, HOLE UP TIME | 1000ms, 50ms, 20ms | |
INPUT | INPUT VOLTAGE RANGE | 85-264V AC |
AC CURRENT | 0.7A @ 230V AC, 1.4A@115VAC | |
INPUT FREQUENCY | 50/60Hz | |
EFFICIENCY | >85% | |
INRUSH CURRENT | COLD START 10A/115V, 20A/230V | |
LEAKAGE CURRENT | <0.5mA when the input voltage is 240V AC | |
PROTECTION | OVERLOAD PROTECTION | 110~200%, TYPE:HICCUP RESET:AUTO RECOVER |
OVER VOLTAGE | 34-42V, shut down out voltage , re-power on to recover | |
ENVIROMENT | WORKINGTEMP, HUMIDITY | -20~60℃, 10~90% RH, non-condensing |
STORAGE TEMP, HUMIDITY | -20~85℃, 10~95% RH | |
TEMPERATURE DRIFT | ±0.03%/℃(0~50℃) | |
SAFETY&EMC | SAFETY STANDARD | GB4943-1,EN62368-1 |
WITHSTAND VOLTAGE | I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | |
INSULATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:500VDC /100M Ohms | |
EMC STANDARD | MEET EN55022 CLASSB | |
OTHER | SIZE | 129*98*30mm(l*W*H) |
WEIGHT | 0.3Kgs | |
The 12V 8.3A Single Output PSU is an essential device that provides power to various electronics and electrical devices. This power supply unit is a reliable source of energy that ensures your devices receive the required amount of power to function efficiently.
When looking for a power supply unit, it is important to consider the output voltage and amperage. This 12V 8.3A Single Output PSU meets these requirements, making it a suitable choice for powering your devices.
Investing in a quality power supply unit like this one can help prolong the lifespan of your electronic devices. By providing stable and consistent power, you are minimizing the risk of damage caused by surges or fluctuations in power.
It is also important to note that this type of power supply unit is easy to install and use. Whether you are a beginner or an experienced user, you won’t have any trouble setting it up or operating it.
Furthermore, a 12V 8.3A Single Output PSU is known for its energy efficiency. This means that it performs well while consuming less power, making it environmentally friendly and cost-effective.
Overall, a 12V 8.3A Single Output PSU is a reliable and beneficial device to have for anyone who values the functionality and longevity of their electronic devices. So, whether you are a professional or just looking for a power supply unit for personal use, choosing this device will not disappoint you.
