DC12V 30A Dc UPS

Item NO

KDC400-12

Output

Output Voltage

CH1: +12VDC;

CH2: +13.8VDC

Rated Current

CH1: 18A;

CH2: 8A

Current Range

CH1: 0-18A;

CH2: 0-8A

Rated Power

350W

Ripple & Noise

CH1: 150mVp-p;

CH2: 200mVp-p

Output Accuracy

CH1:±5%

Line Regulation

CH1: ±0.5%

CH2: +/-1%

Load Regulation

CH1: ±0.5%

CH2: +/-4%

Set up, Rise, Keep up time

300ms, 50ms, 20ms

Input

Input Voltage Range

88-132V AC, 176~264vac by switching

Input Current

6A/115V, 3A/230V

Input Frequency

50~60Hz

Efficiency

> 85%@230V

Inrush Current

Cold start 40A/230V

Leakage Current

< 0.5mA@240V

Protection

Over Load Protection

105~150%, Hiccup protection, automatic recovery

Short Circuit Protection

Hiccup, automatic recovery

Output over-voltage protection

> 150% automatic recovery

Over-temperature protection

＞105 ℃ protection, automatic recovery

Environment

Working Temp., Humidity

-20~50℃, 10~90% RH, No condensation

Storage Temp., Humidity

-20~85℃, 10~95% RH

Safety& EMC Standards

Safety Standards

GB4943

Withstand Voltage

I/P-O/P: 4KV; I/P-FG: 1.5KV; O/P-FG: 0.5KV AC

Insulation Resistance

I/P-O/P, I/P-FG, O/P-FG: 500VDC / 100M Ohms

Others

Dimension

215*115*50mm(L*W*H)

MTBF

> 50hrs
