Guangzhou Kaihui Electronics Co., Ltd. is one of the leading manufacturers and suppliers of dc5v 10a power supply in China. With abundant experience, our factory offer high quality products made in China with competitive price. Welcome to contact us for customized service.
DC5V 10A Power Supply is an essential component in various electronic devices which require a steady and reliable power supply. It provides uninterrupted power supply to the devices where a stable and regulated power supply is vital for their smooth operation.
These power supplies come in various sizes and shapes to fit the needs of a variety of electronic devices. They are designed to operate at low voltage and provide continuous power to the devices. They are equipped with various safety features which make them safe to use.
|
Parameter |
||
|
Model No. |
K28-U60S5 |
|
|
Output |
Output Voltage |
DC5V |
|
Rated Current |
10A |
|
|
Current Range |
0-10A |
|
|
Rated Power |
50W |
|
|
Ripple |
100mVp-p |
|
|
Adjustable Output Range |
±10% |
|
|
Output Accuracy |
±1% |
|
|
Line Regulation |
±0.5% |
|
|
Load Regulation |
±0.5% |
|
|
Set up,Rise,Keep up time |
500ms, 50ms, 20ms |
|
|
Input |
Input Voltage Range |
90~264V AC |
|
Input Current |
0.6A/115V;0.3A/230V |
|
|
Input Frequency |
50/60Hz |
|
|
Efficiency |
>84%@220VAC |
|
|
Inrush Current |
30A@230V |
|
|
Leakage Current |
<0.35mA@240V |
|
|
Protection |
Over Load Protection |
105~150%, TYPE:HICCUP RESET:AUTO RECOVER |
|
Short Circuit Protection |
TYPE:HICCUP RESET:AUTO RECOVER |
|
|
Over Voltage protection |
7-9V |
|
|
Environment |
Working Temp.,Humidity |
-20~50℃,10~90% RH,No condensation |
|
Storage Temp.,Humidity |
-20~85℃,10~95% RH |
|
|
Temp.,Drift |
±0.03%/℃(0~50℃) |
|
|
Vibration |
10~500Hz, 2G 10min /1cycle, PERIOD FOR 60min EACH AXES |
|
|
Safety&EMC Standards |
Safety Standards |
GB4943,EN60950 |
|
Withstand Voltage |
I/P-O/P,I/P-FG:1.5KV,O/P-FG:0.5KV DC 1min |
|
|
Insulation Resistance |
I/P-O/P, I/P-FG, O/P-FG:500VDC / 100M Ohms |
|
|
EMC Standards |
GB9254,EN55022 CLASS A |
|
|
Others |
Size |
105*44*27mm |
|
Weight |
0.2kg |
|
FAQ
Q1:Are you trading company or manufacturer?
A: We are professional manufacturer specialized in switching power supply and transformer. And we trade our products with our clients directly.
Q2: Can we use our own logo?
A: Yes, we can print your private logo according to your request.
Q3: How many packaging do you have?
A: We have three packages including small white box,big box and bigger box currently.
