The new product of 24V 25A, it can pass the EMC testing, we can accept the ODM for the output voltage, current, install dimension and others.

Features:

1, 600W high efficiency 24v single output power supplies;

2, K18C-UP600S24 model have small size, high efficiency;

3, International universal full voltage input;

4, 600W single output 24v built-in active PFC function;

5, Built-in filter, low noise, high reliability;

6, Overload, short circuit, under voltage, over voltage, over temperature protections and etc.

Parameter
Item NO		K18C-UP600S24
Output	Output Voltage	+24VDC
	Rated Current	25A
	Current Range	0-25A
	Rated Power	600W
	Ripple & Noise	400mVp-p
	Adjustable Output Range	22.8~25.2V
	Output Accuracy	±1%
	Line Regulation	±0.5%
	Load Regulation	±1%
	Set up, Rise, Keep up time	300ms, 20ms, 12ms
Input	Input Voltage Range	100~240V AC
	Input Current	3A/230V, 6A/115V
	Input Frequency	50~60Hz
	Efficiency	92%@230VAC, 90%@100VAC
	Power Factor	PF＞0.98/115V PF＞0.95/230V
	Inrush Current	Cold start 60A@230V
	Leakage Current	< 0.5mA@240V
Protection	Over Load Protection	105~150%, Hiccup protection, automatic recovery
	Short Circuit Protection	Locked protection, return to normal after restart
	Output over-voltage protection	＞120% Shut down, Locked protection, return to normal after restart
	Over-temperature protection	TS1 position＞105℃ it will be protection, then automatic recovery
Environment	Working Temp, Humidity	-20~60℃, 10~90% RH, No condensation
	Storage Temp, Humidity	-20~85℃, 10~95% RH
	Temp, Drift	±0.03%/℃(0~50℃)
	Vibration	10~500Hz, 2G 10min /1cycle, PERIOD FOR 60min EACH AXES
Safety& EMC Standards	Safety Standards	GB4943, EN60950
	Withstand Voltage	I/P-O/P:3KV; I/P-FG:1.8KV; O/P-FG:0.6KV AC 1min
	Insulation Resistance	I/P-O/P, I/P-FG, O/P-FG:500VDC / 100M Ohms
	EMC Standards	EN55022 Class B, EN61000-3-2
Others	Dimension	1688240mm(LWH)
	Weight	0.68kg
	MTBF	＞50K hrs MIL-HDBK-217F(25℃)
	Fan Supply	12V@0.3A for driving a fan, tolerance±15%
Notes	1. All parameters 230VAC input, rated load, ambient temperature 25 ℃, measured under conditions of 70% humidity; 2. Accuracy: includes set up tolerance, line regulation, load regulation and so on; 3. Ripple Test: 30cm long strands connect the power supply and the load on the load side and 0.1u and 47u capacitor to 20MHz oscilloscope measured at the load end; 4. Line regulation: at rated load conditions, the input voltage changes from low to high measured; 5. Load regulation: the measured output load from 0 to 100% load change measured.
