Guangzhou Kaihui Electronics Co., Ltd. is one of the leading manufacturers and suppliers of 12 vdc 800watt power supply in China. With abundant experience, our factory offer high quality products made in China with competitive price. Welcome to contact us for customized service.
The 12 VDC 800-Watt Power Supply is a high-capacity, enclosed switching power solution engineered to deliver up to 66.6A of clean, continuous direct current. To manage this substantial output safely, the unit integrates an active Power Factor Correction (PFC) network, which optimizes electrical efficiency and significantly reduces harmonic distortion on the local grid. Housed in a robust, ventilated metal chassis with built-in intelligent forced air cooling, this module functions as the reliable backbone for energy-intensive electronic clusters where voltage drop or current fluctuations cannot be tolerated.
Technical Parameters
|
OUTPUT SPECIFICATION |
|
|
Item |
K19H-UP1000S12F |
|
Output voltage |
+12VDC |
|
Rated current |
67A |
|
Rated power |
804W |
|
Ripple &noise |
200mVp-p |
|
Output adjustable range |
±5% |
|
Output accuracy |
±1% |
|
Line regulation |
±0.5% |
|
Load Regulation |
±0.5% |
|
Cross Regulation |
-- |
|
Setup, rise, hold up time |
500ms, 30ms, 5ms/115VAC 300ms, 30ms, 10ms/230VAC |
|
INPUT SPECIFICATION |
|
|
Rated input voltage |
90-264V AC |
|
Input voltage range |
88-264VAC |
|
Input Current |
10A/115V , 5A/230V |
|
Frequency Range |
47-63 Hz |
|
efficiency |
92% @230V,89% @115V |
|
Power factor |
>0.98@110V;>0.95@220V |
|
Inrush current |
Cold start 40A/230V |
|
Leakage current |
<3.5mA@240V AC |
|
PROTECTION FUNCTION |
|
|
Overload protection |
105~135%,Hiccup protection, automatic recovery |
|
Output short circuit protection |
Lock out protection, power off then automatic recovery |
|
Output over voltage protection |
15-18V |
|
Over temperature protection |
Enclosure＞105℃. Shut down, recovers automatically after temperature goes down. |
|
OTHER FUNCTION |
|
|
Auxiliary power supply |
12V0.3A auxiliary voltage output is provided |
|
Standby function |
RC terminal, increase the high level, turn off the output |
|
ENVIRONMENT |
|
|
Working temp.,humidity |
-20~60℃,10~90% RH,No condensation |
|
Temperature Coefficient |
±0.3%/℃(0~50℃) |
|
Vibration |
10~500Hz, 2G 10min./1cycle, PERIOD FOR 60min. EACH AXES |
|
● All parameters are measured under the conditions of 230VAC input, rated load, ambient temperature 25℃ and humidity 70%; ● Accuracy:including setting error, line regulation,load regulation, etc. Line regulation: measured with the input voltage changes from low to high under rated load conditions; Load regulation: measured with output changes from 0 load to 100% load; Ripple test: Connect the power supply and the load with a 30cm-long twisted wire. The load end is connected with 0.1u and 47u capacitors, and it is measured at the load end with a 20MHz oscilloscope; |
|
Product Advantages and Features
- Advanced Active PFC Design: Achieves a power factor of up to 0.98, ensuring maximum power utilization and compliance with strict international grid regulations.
- Excellent Efficiency Rating: Converts energy with minimal thermal loss, reducing the cooling load on the surrounding cabinet infrastructure.
- Comprehensive Safety Redundancy: Outfitted with robust protection circuitry against over-current, short-circuits, over-voltage, and internal over-temperature anomalies.
- Rigorous Component Selection: Built using industry-recognized CAPXON brand capacitors, ensuring a long operational life and keeping the factory repair rate at an exceptionally low 0.1% to 0.2%.
- Verified Electromagnetic Compliance: Thoroughly validated in professional EMC laboratories to ensure it operates cleanly without disrupting nearby precision sensors or wireless communication lines.
- Smart Thermal Regulation: Features an internal cooling fan that responds dynamically to temperature changes, striking a balance between component longevity and acoustic control.
Application Scenarios
- Telecom and Server Racks: Providing consistent 12V rails to multi-node computing setups, networking routers, and high-speed data arrays.
- Industrial Automation Equipment: Supplying robust current to multi-axis CNC machines, heavy stepper motors, and high-frequency production lines.
- High-Density LED Displays: Driving massive commercial video walls and outdoor stadium screens that demand sudden, high-peak current without flickering.
After-Sales Service & FAQ
- Standard Two-Year Warranty: Every unit comes with a two-year quality guarantee, offering robust coverage during the critical deployment phase.
- Logistic and Export Assistance: Direct support for shipping arrangements, vessel booking, customs documentation, and factory audit verifications.
- Rapid Engineering Feedback: Dedicated technical response protocols ensure integration questions or field reports are resolved efficiently to guarantee client satisfaction.
FAQ
Q1: What is the typical production timeline for large bulk orders?
A: Once the project deposit is confirmed, the mass production and scheduling cycle for standard enclosed units generally takes 20 to 25 working days.
Q2: Can we modify the physical dimensions or add custom logos to the unit?
A: Yes. Full OEM and ODM services are available. This includes custom branding on the aluminum case, tailored wire configurations, and private label packaging designed to fit your corporate aesthetics.
Q3: Is it possible to request evaluation units before a major roll-out?
A: Sample orders are encouraged for rigorous validation. Typically, 1 to 5 prototype pieces can be provided, with custom sample preparation taking 7 to 10 working days after details are finalized.
